Tall Timber
Fader
Expression or Volume Fader
Fader Features:
Fader is a stripped-down version of the more fully-featured Fader DLX
Use as an expression controller or as a volume control
45mm fader travel
Powder-coated aluminum enclosure with carved walnut top
Available in 10kOhm, 100kOhm resistances with linear taper and 10kOhm 50kOhm Audio Taper
Click here for help selecting the right fader
Specifications
-
Dimensions
96 x 38 x 46 mm
(3.8 x 1.5 x 1.8 in)
-
Materials
Enclosure: Powder-coated machined cast aluminum
Fader Cap: Plastic w/ Steel Set-Screw
Top: Carved Solid Walnut
-
10k Linear Model Details
Fader Resistance: 10kOhms +/-20%
Fader Taper: Liner
Enclosure Color: Matte Black
Fader Cap Color : Black w/ White Stripe
-
10k Audio Model Details
Fader Resistance: 10kOhms +/-20%
Fader Taper: Audio (Log)
Enclosure Color: Matte White
Fader Cap Color : White w/ Black Stripe
-
100k Linear Model Details
Fader Resistance: 100kOhms +/-20%
Fader Taper: Linear
Enclosure Color: Matte Green
Fader Color: Green w/ White Stripe
-
50k Audio Model Details
Fader Resistance: 50kOhms +/-20%
Fader Taper: Audio (Log)
Enclosure Color: Green Earth
Fader Cap Color: White w/ Black Stripe
-
What's Included
Tall Timber Fader
Optional Rubber Feet
Protective Muslin Bag
Product Box
Functions
Dimensions
